30% Long Glass Fiber Reinforced PPS (LFT-PPS-LGF30-NG03)
This is our premier solution for the most hostile chemical and thermal environments. LFT-PPS-LGF30-NG03 combines the exceptional dimensional stability and strength of a 30% long glass fiber structure with the inherent chemical immunity and high-heat dominance of a Polyphenylene Sulfide (PPS) matrix. It is engineered to perform where other high-performance plastics fail. In short, this page details an engineering solution for extreme environments (LFT-PPS-LGF30-NG03) - blending the strength of 30% long fiber with the superior chemical and thermal resistance of PPS for the most demanding automotive fluid systems and industrial pump parts.
People Also Ask:
What is PPS GF30?
It is a high-performance composite made from a PPS matrix with 30% glass fiber. Our long-fiber version enhances this with superior toughness, making it ideal for structural auto parts and pump parts exposed to harsh chemicals.
What is PPS plastic resistant to?
PPS offers the broadest chemical resistance of any advanced engineering plastic. It is virtually immune to automotive fluids, fuels, strong acids, bases, and solvents, even at temperatures up to 200°C (400°F).
Is PPS better than PEEK?
While PEEK offers slightly higher temperature performance, PPS provides comparable chemical resistance and excellent mechanical properties at a significantly more cost-effective price point, making it the superior value choice for many high-end applications.
Environmental Performance Dashboard
Broad Chemical Resistance (at 80°C)
| Automotive Gasoline | Excellent |
| Brake Fluid (Glycol) | Excellent |
| Sulfuric Acid (30%) | Excellent |
| Sodium Hydroxide (10%) | Excellent |
Strength Retention at High Temperature
LFT-PPS-LGF30 retains a high percentage of its strength even at 200°C, while polyamides (dashed line) see a significant drop-off.
Case Study: Industrial Chemical Pump Housing
The Challenge
A manufacturer of industrial pumps for the chemical processing industry needed to replace a stainless steel pump housing. While durable, the metal housing was extremely heavy, expensive to machine, and had long lead times. They required a thermoplastic that could withstand a continuous flow of aggressive solvents and acids at temperatures exceeding 150°C, without swelling, cracking, or degrading over a long service life.
The Solution: LFT-PPS-LGF30-NG03
Our PPS long-fiber composite was the only material that met the extreme chemical and thermal requirements. The PPS matrix provided near-universal chemical immunity, while the 30% long glass fiber core delivered the mechanical strength and creep resistance to handle high internal pressures. We provided extensive compatibility data and worked with their team to ensure the mold design accounted for the unique processing characteristics of PPS.
Result: A 70% lighter pump housing that passed all chemical immersion and pressure cycle tests, with a 40% reduction in production cost and a 60% faster manufacturing time.
Visit More Details Of PPS Pump Part...
Technical Specifications (Grade: LFT-PPS-LGF30-NG03)
| Property | Test Method | Value |
|---|---|---|
| Density | ISO 1183 | 1.56 g/cm³ |
| Tensile Modulus | ISO 527 | 12,500 MPa |
| Tensile Strength | ISO 527 | 175 MPa |
| Notched Izod Impact (23°C) | ISO 180 | 45 kJ/m² |
| Heat Deflection Temp (1.8 MPa) | ISO 75 | 260 °C |
| Flame Retardancy (1.5mm) | UL94 | V-0 (Inherent) |
| Water Absorption (24hr) | ISO 62 | < 0.05% |
Solving Challenges in Hostile Environments
Challenge: Handling Aggressive Automotive Fluids
Components in fuel, cooling, and braking systems must withstand constant exposure to corrosive fluids at high temperatures without degradation.
- Fuel Pump Housings
- Coolant System Valves
- Brake System Components
Challenge: Ensuring Precision in High-Heat Electronics
High-power electrical connectors and sensor housings require excellent dimensional stability and property retention through thermal cycling.
- SMT Connectors
- Sensor Housings
- Coil Bobbins
Challenge: Replacing Metal in Industrial Processing
Components in the oil & gas and chemical industries demand the strength of metal but suffer from its weight, cost, and susceptibility to corrosion.
- Chemical Pump Impellers
- Valve Bodies
- Downhole Oil & Gas Components
Solve Your Toughest Material Challenges
When standard plastics can't withstand the heat or the chemical exposure, LFT-PPS-LGF30-NG03 is the answer. Contact our engineering team to discuss your most hostile-environment application and find a solution that lasts.
