What is PP GF20 ?
LFT-G® NG02C PP GF20 is a 20% long glass fiber reinforced Polypropylene composite with natural grade Copo-polymer. This long glass fiber polypropylene is an excellent entry-point into high-performance composites, offering a significant boost in properties over unfilled PP. By reinforcing a tough copolymer with 20% glass fiber, this PP GF20 material achieves an outstanding balance of impact resistance, improved stiffness, and excellent surface finish. It is ideal for semi-structural components in automotive and consumer goods where toughness and aesthetic appearance are key requirements, providing a cost-effective upgrade from commodity plastics.
PP-GF20 material properties?
LFT-G® NG02C PP-GF20 Datasheet
Mechanical PropertiesProperty |
Value |
Unit |
Test Standard |
|---|---|---|---|
| Tensile Strength | 108 | MPa | ISO 527 |
| Tensile Modulus | 5406 | MPa | ISO 527 |
| Elongation at Break | 2.2 - 2.6 | % | ISO 527 |
| Flexural Strength | 133 | MPa | ISO 178 |
| Flexural Modulus | 3856 | MPa | ISO 178 |
| Notched Izod Impact Strength (23°C) | 32 | kJ/m² |
ISO 180
|
| Notched Charpy Impact Strength (23°C) | 29 | kJ/m² |
ISO 179
|
Other PropertiesProperty |
Value |
Unit |
Test Standard |
|---|---|---|---|
|
Specific Gravity (Density)
|
1.05 |
g/cm³
|
ISO 1183
|
|
Molding Shrinkage (Flow)
|
0.2 - 0.4 | % |
ISO 294-4
|
|
Heat Deflection Temperature (1.8MPa)
|
155-159 |
°C
|
ISO 75-2/A
|
|
Melt Temperature
|
210 - 250 |
°C
|
|
|
Mold temperature
|
40 - 80 |
°C
|
Disclaimer: Please note: The data provided for LFT-G® PP GF20 represents typical values obtained from controlled laboratory testing according to international standards. These figures are intended for reference and comparison purposes only. The final properties of a molded component can be influenced by processing parameters, part design, colorant usage, and other manufacturing variables.
Download Complete NG02C PP-GF20 Data Sheet PDF
Processing Information
To achieve the best results with LFT-G® PP GF20, standard injection molding guidelines should be followed with a focus on preserving fiber length. The 20% glass fiber content provides excellent flow characteristics while enhancing mechanical properties, making it a robust and process-friendly material for a wide range of molding applications.
| ①Drying Time | 2-4 hours |
|
Drying Temperature |
80-100°C |
| ② Temperature Zone (Melt) | 220-240°C |
| ③Mold Temperature | 40-80°C |
Benefits of Long fiber PP
- Excellent impact strength and toughness.
- Improved stiffness and strength over unfilled polypropylene.
- Good dimensional stability and low warpage.
- Superior surface finish for aesthetic components.
- Great balance of performance and processability.
- Lightweight with good chemical resistance.
What is PP-GF20 used for?
PP-GF20 Automotive
Thanks to its excellent toughness and surface quality, this material is a popular choice for semi-structural and visible interior automotive components, such as in the manufacturing of parts for PP-GF20 honda models and other leading brands.
- Interior door panels
- Center consoles
- Glove box assemblies
- Seat back panels
- Pillar trim
- Trunk liners
- Under-hood covers
- Fan shrouds
Pump&Home Appliance Component
This material is ideal for durable appliance parts and pump components where good chemical resistance and impact strength are needed, as seen in a PP GF20 filter housing.
- Washing machine control panel housings
- Dishwasher cutlery baskets and front panels
- Vacuum cleaner bodies
- Air purifier housings
- Lawnmower decks
- Power tool casings
- Small pump bodies
FAQ
Q: What is the density of PP GF20 ?
A: The exact density for LFT-G® PP GF20 can be found in the product's technical datasheet,PP GF20 density is 1.05g/cm³. Generally, a 20% glass-filled polypropylene has a density significantly lower than higher-filled grades, contributing to its excellent balance of weight and performance.
Q: What is the use of PP copolymer?
A: A PP copolymer is used to enhance properties like impact resistance and low-temperature toughness compared to standard PP copo-polymer. It provides a more durable and resilient base matrix for our long glass fiber polypropylene composites.
Q: What is a PP pellet?
A: A PP pellet is the small, granulated form in which the raw polypropylene composite material is supplied to manufacturers. Our LFT-G® PP GF20 pellets contain the polypropylene resin and the long glass fibers, ready for the injection molding process.
