Name: China LFT-G® PP LGF30-C:Impact Upgrade For PP GF30 Factory, Manufacturers and Suppliers - LFT-G
Brand: LFT-G®
SKU: 284778026

LFT-G® PP LGF30-C | The High-Impact Upgrade for PP GF30

Product Description & Features

LFT-G PP LGF30-C material - extreme toughness copolymer LFT-G^® PP LGF30 -NG03C is the ultimate toughness upgrade for designs specifying "PP GF30". Standard PP GF30 (short fiber) is often selected for its stiffness, but it is notoriously brittle and fails catastrophically upon impact, especially in cold weather. LFT-G^® PP LGF30-NG03C is a copolymer (Copo) grade specifically engineered to solve this problem.

By combining a 30% long glass fiber network with a high-impact copolymer matrix, this material provides unparalleled durability. The long fibers create a "rebar-like" skeleton that stops cracks, while the copolymer base absorbs impact energy.

√ Extreme Impact Resistance: Offers 3-5 times the impact strength of standard PP GF30, preventing failures from drops or collisions.
√ Superior Low-Temp Toughness: Remains ductile and fracture-resistant in sub-zero conditions where homopolymer grades (including SGF PP GF30) become extremely brittle.
√ Excellent Processability: Provides a great balance of toughness and melt flow, making it ideal for molding complex, durable parts with features like snap-fits and bosses.

Typical Material Properties

The following values are typical data for LFT-G^® PP LGF30 -NG03C (natural copolymer grade) and are for reference only. Please contact us for the official Technical Data Sheet (TDS).

Mechanical Properties

Property	Test Method	Value
Tensile Modulus	ISO 527	7,200 MPa
Tensile Strength	ISO 527	121 MPa
Tensile Strain at Break	ISO 527	2.8 %
Flexural Modulus	ISO 178	6,600 MPa
Notched Izod Impact (23°C)	ISO 180/A	42 kJ/m²
Notched Izod Impact (-30°C)	ISO 180/A	25 kJ/m²

Thermal & Physical Properties

Property	Test Method	Value
Density	ISO 1183	1.11 g/cm³
HDT/A (1.8 MPa)	ISO 75	159 °C
HDT/C (8.0 MPa)	ISO 75	138 °C
Melting Temperature	ISO 11357	~163 °C
Mold Shrinkage (Flow)	ISO 294-4	0.2 - 0.5 %

Download Complete LFT^® PP GF30-C TDS (PDF)

Processing Information

The following values are recommendations. We recommend desiccant / dry air dryers (moisture content below 0.1%).

To minimize fiber breakage and ensure optimal performance, a low-compression, general-purpose screw is highly recommended.

Parameter	Recommendation
Drying Temperature	80 - 100 °C
Drying Time	2 - 4 hours
Melt Temperature (Nozzle ③)	220 - 250 °C
Mold Temperature (Zone ②)	40 - 70 °C
Back Pressure	Low (to minimize fiber damage)

Injection molding Process info

Typical Applications for PP LGF30 Copolymer

The extreme toughness of LFT-G® PP LGF30-C makes it the ideal choice for parts that must withstand impact and abuse, especially in cold environments.

● Child Safety Seat Structures
● Automotive Bumper Energy Absorbers
● Snowmobile & ATV Components
● Power Tool Housings (Heavy Duty)
● Ruggedized Equipment Cases
● Industrial Pallets & Totes
● Sporting Goods (e.g., Ski Boots)
● Office Furniture (Chair Bases/Arms)
● Fan Blades (for Impact Resistance)
● Automotive Interior Trim Clips

Case Study: Child Safety Seat Structure

A child safety seat base demonstrating high impact protection

Challenge

A premium manufacturer needed a material for their next-gen safety seat. The design had to pass stringent side-impact crash tests at both +70°C (hot car) and -30°C (winter), where standard PP GF30 becomes brittle and shatters.

Solution

LFT-G^® PP LGF30-C was chosen. The long-fiber network provided the stiffness to maintain the shell's structural integrity, while the copolymer matrix ensured high ductility and energy absorption, preventing any brittle failure during low-temperature crash testing.

Result

The design passed all safety standards with a 40% safety margin. The material's reliability allowed for a 15% weight reduction in the part, improving ease-of-use for parents and reducing manufacturing costs.

Applications for High-Toughness PP LFT

A rugged snowmobile structural component

Snowmobile & ATV Components

The ultimate test of low-temperature toughness. LFT PP LGF30-C is used for structural parts that must withstand impacts from rocks and ice in sub-zero conditions without shattering.

Automotive bumper energy absorber bracket

Bumper Energy Absorbers

Used in automotive safety systems, this material is designed to absorb and dissipate kinetic energy during a low-speed crash, protecting more expensive components and passing safety tests.

A heavy-duty industrial pallet for cold storage

Cold Storage Pallets

Replaces standard plastics that become brittle in freezers. LFT PP LGF30-C offers the rigidity for racking and the high impact strength to withstand forklift abuse in cold storage warehouses.

Key Questions Answered

1. Why choose this Copolymer (C) grade over the Homopolymer (H) PP LGF30?

A: The choice is all about toughness. The Homopolymer (H) grade is stiffer and has a slightly higher heat resistance. This Copolymer (C) grade is engineered for maximum impact strength and durability, especially in low temperatures. If your part will be dropped, struck, or used below freezing, this Copolymer grade is the superior choice.

2. What is the main advantage of LFT PP LGF30-C over a standard PP GF30?

A: Reliability. A standard short-fiber PP GF30 is brittle. It will shatter on impact. The long-fiber network in our LFT grade, combined with a tough copolymer base, creates a material that absorbs energy and resists fracture, dramatically increasing part longevity and safety.

3. Can this material be used for snap-fit components?

A: Absolutely. This is an ideal application. The high ductility of the copolymer matrix allows for robust, flexible snap-fit clips, while the long-fiber reinforcement provides the strength and fatigue resistance to ensure they can be used thousands of times without breaking or weakening.

Ready to Engineer the Next Breakthrough?

Elevate your product's performance with the extreme toughness and durability of LFT-G^® PP LGF30 Copolymer. Contact our material specialists today to discuss your project or request a material sample.

Request a Sample Contact an Engineer
