LFRT Pa66 Carbon Fiber

Details

LFT-G® Xiamen LFT Composite Plastic Co.,Ltd is a unique long fiber reinforced thermoplastics plastic manufacture.
Our material have following properties.
1.Improved impact
2.Safer impact mode
3.Reduced warpage
4.Improved creep resistance

LFRT Pa66 Carbon Fiber

Long Carbon Fiber Reinforced PA66
Grade : Injection molding Color : Black		Form : LFT Pellets Filler content : Long carbon fiber
Grade	Filling Specifications	Product number	Feature
General grade	10%	PA66-NA-LCF10	High toughness, light weight, high strength, wear resistance, corrosion resistance
	20%	PA66-NA-LCF20
	30%	PA66-NA-LCF30
	40%	PA66-NA-LCF40
	50%	PA66-NA-LCF50
	60%	PA66-NA-LCF60
We can customize according to customer's requirements.

long carbon fiber advantage1.jpg

The product properties of PA-NA-LCF30
Item	Typical Characteristic	Testing Standard
Specific Gravity	1.27 g/cm³	ASTM D-792
Tensile Strength	276 MPa	ASTM D-638
Tensile Modulus	23448 MPa	ASTM D-638
Tensile Elongation	1.0 - 2.0 %	ASTM D-638
Flexural Strength	400 MPa	ASTM D-790
Flexural Modulus	19310 MPa	ASTM D-790
Notched Izod Impact	187 J/m	ASTM D-256
Un-Notched Izod Impact	801 J/m	ASTM D-4812
Deflection Temperature @264 psi (1820 kPa)	249 °C	ASTM D-648
Flame Retardant	HB @ 1.5 mm	ASTM D-635
