pa6 pellets pa6-gf30 potentiometer
Long Fiber's Uniqueness
The full name of the pa6 pellets pa6-gf30 potentiometer is a 30%long glass fiber reinforced PA6 that uses a method of injection molding to fuse the fibers and the matrix resin together and maximizes their performance and is characterized by a continuous fiber filament length over the entire length of the pellet , Making these materials have both strength, stiffness and impact resistance improvements over a wide temperature range. LFT composites are widely accepted as a viable alternative to traditional reinforced thermoplastics and metals for a variety of applications.
Skeletal Fiber Network
◆ pyrolysis burns away plastic to reveal internal fiber structure of injection molded component.
–During molding longer fibers align and intertwine to form internal skeletal fiber network.
–Retention of detail shows structural propeties present in these elements
Properties of pa6 pellets pa6-gf30 potentiometer
|
LFT-G® PA6 LGF30 LFT-PA6-NA-LGF30 Natural Color Injection Moulding |
||
| Test Item | Typical Characteristic | Testing Standard |
| Specific Gravity | 1.36 | ASTM D-792 |
| Molding Shrinkage | 0.10-0.30% | ASTM D-955(1/8 in (3.2 mm) section) |
| Tensile Strength | 174 MPa | ASTM D-638 |
| Tensile Modulus | 9655 MPa | ASTM D-638 |
| Tensile Elongation | 2.0-3.0% | ASTM D-638 |
| Flexural Strength | 268 MPa | ASTM D-790 |
| Flexural Modulus | 9655 MPa | ASTM D-790 |
| Notched Izod Impact | 240 J/m | ASTM D-256 |
|
Deflection Temperature @ 264 psi (1820 kPa) |
854 J/m | ASTM D-648 |
| Flame Retardant | HB @ 1.5 mm | ASTM D-635 |
Application of pa6 pellets pa6-gf30 potentiometer
LFT Certification
Packing&Delivery
Thermoplastic Urethanes with Long glass fiber Packing
Sample: free ,but freight charged on customers Delivery Time: 5-15days Delivery Method: by seashipments( FCL OR LCL), by airshipments, by express; or customized; Weights: 20-25kgs/bag
|
