LFT Material
What is PA6 LCF40?
LFT-G® PA6 LCF40 is a nylon6 compound that made using a combination of 40%long carbon fiber and polyamide 6, which gives it incredible strength and durability.PA6 LCF40 is one of the most popular materials used in the manufacturing sector.The material is highly resistant to a wide range of chemicals and solvents, making it an ideal choice for applications in the automotive, aerospace, and manufacturing industries.
Carbon fiber (CF) is made from polyacrylonitrile, asphalt, viscose and other raw materials through the process of pre-oxidation, carbonization or graphitization, and has the advantages of light weight, high strength, high modulus, high temperature resistance, corrosion resistance, and good thermal and electrical conductivity.
PA6 LCF40 material has the following advantages:
(1) light weight, high strength, high modulus;
(2) good corrosion and heat resistance;
(3) flexible design, high production efficiency;
(4) production waste and products can be recycled.
Mechanical Properties
LFT-G® PA6 LCF40 BC04A Grade
| Mechanical | Typical Valus | Unit | Test Stardant |
|
Specific Density Molding Shrinkage |
1.29 0.1-0.2 |
g/cm³
%
|
ASTM D-792
ASTM D-955
|
|
Tensile Strength Tensile Modulus |
268 30998 |
Mpa Mpa |
ISO 527/1A ISO 527/1A |
|
Flexural Strength Flexural Modulus |
384 21867 |
Mpa Mpa |
ASTM-D790 ASTM-D790 |
|
Charpy Impact Strength Notched |
30 |
KJ/m2
|
ISO 179 |
|
More technical data, visit our data center |
Advantages of LFT long fiber composite
Extremly Mechanical Properties
Keep longer glass carbon fiber,the LFT long fiber composite will provide higher stiffness strength,high modulus, thoughness than short fiber reinforced material
Strong dimensional durability
LFT long fiber composite is made of high-strength fiber materials such as high-flow Polypropylene/Nylon , which greatly improves its durability and strength.
Excellent Chemical Corrosion
LFT Composite choose multi matrix resin from PP to PEEK,Very good corrosion and chemical resistance Retains performance across low and elevated temperatures
Due to its exceptional mechanical properties, PA6 LCF40 is widely used in many industries, such as:
- Automotive: PA6 LCF40 is widely used in the automotive industry for applications that require a high level of structural integrity such as door handles, pedals, and engine parts. It also finds use in various interior parts for its excellent aesthetics, durability, and design flexibility.
- Aerospace Industry: PA6 LCF40's high strength-to-weight ratio, temperature resistance, and design flexibility are ideal for the aerospace industry. It finds use in various structural components, such as brackets, housings, and interior parts.
